Home LAN recommendations

M

midnightcaller

Expert Member
Joined
Jul 24, 2010
Messages
2,330
Reaction score
169
Location
gauteng
Current setup at home.
Vox on Vumatel fibre
Raycore router for fibre. Supplied by Vumatel.
Haplite router for wired and wireless LAN. Supplied by vox about 3/4 years ago.

I want to remove the haplite and upgrade to get stronger and wider wifi signal strength around the house and improved wifi security.

Requirements :
Wireless Access points in 2 or 3 different areas in the house.
Router with some advanced features that I can self manage on the basics.
Wifi 6
wifi security protocols WPA2/3
Guest ssid - must be able to limit access and speed.
Private ssid for all my wireless devices.

I need some recommendations for setup and equipment.

Router of your choice..

Ubiquity unifi WiFi 6 access points.. scoop does not currently have these on their website but, do have other WiFi 6 ubiquity products, so I imagine they should have them in due course..

What is your budget?

If your house doesn't have a lot of devices (like 30+) and it's large enough to need multiple access points, 802.11ax doesn't really matter and you're paying for a premium for a feature you don't need (most Wi-Fi 6 routers are quite a bit more expensive as it's a relatively new feature to up sell with).

Can you create a floor plan with measurements of your house and wall type and thickness?

Most likely two cheaper routers with beam forming should be fine, since I don't think your current router supports it https://mikrotik.com/product/RB941-2nD-TC it doesn't support 802.11ac or beam forming, so you'll see quite an improvement with just a single better one, so check floor plan size and how crowded wifi is in your area.

The raycore is not a router, it's a CPE, leave it alone.

Johnatan56 said:
What is your budget?

If your house doesn't have a lot of devices (like 30+) and it's large enough to need multiple access points, 802.11ax doesn't really matter and you're paying for a premium for a feature you don't need (most Wi-Fi 6 routers are quite a bit more expensive as it's a relatively new feature to up sell with).

Can you create a floor plan with measurements of your house and wall type and thickness?

Most likely two cheaper routers with beam forming should be fine, since I don't think your current router supports it https://mikrotik.com/product/RB941-2nD-TC it doesn't support 802.11ac or beam forming, so you'll see quite an improvement with just a single better one, so check floor plan size and how crowded wifi is in your area.

The raycore is not a router, it's a CPE, leave it alone.
Click to expand...

I will not be interfering with the Raycore.


Some information that I didn’t provide

House is very old. It’s not open plan. Single floor with a ceiling. Circa 230sqm. 3 beds, Lounge, kitchen, dining room, tv room, study. It has a long passage.
Inside walls are single brick.

Devices
Cctv DVR
Raspberry pi
Samsung smart tv
Xiaomi TV box
3 x smart phones
4 x laptops


Lots of YouTube and Netflix streaming

I started looking at

Netgear Nighthawk AX8 (RAX80)
TP-Link Archer AX6000
Asus wifi 6


Something I still need to figure out.
When Swapping over from the existing haplite to the new wireless router, what will I need from vox telecom to setup the wireless router.

This is what I did, I probably should of gone all in on Ubiquity but i had the protectli box already

Get router hardware but install opensource router software i got one of these https://protectli.com/product/fw4b/ (Install Proxmox, Run opnsense and a basic linux OS for a docker server to run the unifi controller software)
Buy a decent POE switch that supports Vlans if you need it or just go unmanaged
I got one of these and it sorts out my whole flat https://unifi-flexhd.ui.com

midnightcaller said:
Current setup at home.
Vox on Vumatel fibre
Raycore router for fibre. Supplied by Vumatel.
Haplite router for wired and wireless LAN. Supplied by vox about 3/4 years ago.

I want to remove the haplite and upgrade to get stronger and wider wifi signal strength around the house and improved wifi security.

Requirements :
Wireless Access points in 2 or 3 different areas in the house.
Router with some advanced features that I can self manage on the basics.
Wifi 6
wifi security protocols WPA2/3
Guest ssid - must be able to limit access and speed.
Private ssid for all my wireless devices.

I need some recommendations for setup and equipment.
Click to expand...
Have you considered a mesh system? I have an old Dlink router for fibre combined with triple airties mesh kit.

Or just adding a range extender eg Linksys RE9000 MU-MIMO Range Extender? It covers 3000 m² so if placed using its spotfinder technology, should be a game changer. Or so the theory goes.

Considering one myself. Possibly with a Linksys EA9500 Max-Stream AC5400 MU-MIMO Gigabit Router.

Huawei B315 for my LTE adequate for my purposes as limited to one spot for media streaming.

PS.

www.howtogeek.com

Wi-Fi 6 Is Here: Should You Upgrade to Wi-Fi 6 in 2020?

Wi-Fi 6 hardware is already here, and you're sure to see a lot more released throughout 2020.
www.howtogeek.com www.howtogeek.com
